BRI-MAR Hydraulic Dump System Parts

Stock# 7110046
BRI-MAR single cylinder hydraulic pump with remote and 2.5 gallon horizontal mount reservoir is a direct replacement for your single cylinder Bri-Mar dump trailer. Comes complete with solenoid, switch and remote with 20' Cable.

Stock# 7110047
BRI-MAR twin cylinder hydraulic pump with remote and 4.5 gallon horizontal mount reservoir is a direct replacement for your twin cylinder Bri-Mar dump trailer. Comes complete with solenoid, switch and remote with 20' Cable.

Stock# 7110068
BRI-MAR 4" Hydraulic Cylinder for 10,000 to 12,000 lb LP, LE and R series Dump Trailers. Accepts a 1" pin and center to center pin when compressed is 35-1/2". Max PSI for unit is 3,000 PSI.

Stock# 7110075
BRI-MAR Hydraulic Cylinder Mounting Pin measures 1" x 7" and has two retainer holes.

Stock# 7110165
BRI-MAR 3" Hydraulic Cylinder Seal Kit is the older version and was specifically designed to replace the seals and O-rings on a 3" hydraulic cylinder found on BRI-MAR trailers produced in 2012 or prior.

Stock# 7110072
BRI-MAR 4" Hydraulic Cylinder Seal Kit is specifically designed to replace the seals and O-rings on a 4" hydraulic cylinder found on BRI-MAR trailers.

Stock# 7110074
BRI-MAR Hydraulic Cylinder Seal Kit is for Olson telescoping hydraulic cylinders found on BRI-MAR trailers 2012 and newer.

Stock# 7110049
BRI-MAR horizontal mount hydraulic reservoir has a 2.5 gallon capacity and measures 7" W x 7" H x 20" D. Cap and clamp are included.

Stock# 7110050
BRI-MAR horizontal mount hydraulic reservoir has a 4.5 gallon capacity and measures 10" W x 10" H x 15" D. Cap and clamp are included.

Stock# 7110052
BRI-MAR Hydraulic Reservoir Cap has 1" thread and is designed for use on Bucher systems commonly found on BRI-MAR trailers.

Stock# 7110053
BRI-MAR Hydraulic Bucher Pump Starter Solenoid for bucher pumps on BRI-MAR trailers manufactured before 2003. Silver Canister

Stock# 7110054
BRI-MAR Hydraulic Bucher Pump Starter Solenoid for Bucher pumps on BRI-MAR trailers manufactured after 2003. Black Canister.

Stock# 7110056
BRI-MAR Coil, 2-Way / 2-Position Magnet is an encapsulated coil designed for heavy duty hydraulic valve applications. Hole through center is 1/2" diameter.

Stock# 7110057
BRI-MAR Remote with Cord is for the Power Up / Gravity Down function commonly found on hydraulic power units for dump bodies. Wiring harness has three wires come out the end: Black with ring terminal, white with a U-shaped terminal and a green wire.

Stock# 7110058
BRI-MAR Remote with Cord is for the Power Up / Power Down function commonly found on hydraulic power units for dump bodies. Wiring harness has four wires come out the end: Black with ring terminal and white, red, and green, with a U shaped terminal.

Stock# 7110059
BRI-MAR Wireless Remote Control System includes: (2) remote key fob transmitters, (1) receiver module and (1) antenna. The typical range for the remote key fob is 50-100 ft. The receiver module and transmitters are water resistant. Detailed instructions are included which makes for an easy installation.

Stock# 7110028
BRI-MAR 7-Way RV Plug with five foot cord.

Stock# 7110061
BRI-MAR 3/8" Male ORB - (2) 3/8" Female ORB T-Fitting.
SUPPLIES LIMITED -  (1) REMAINING IN STOCK

Stock# 7110043
BRI-MAR Gas Spring for Pump Box is designed to aid in opening and closing the pump box on BRI-MAR trailers made before January 2014.
Extended Length: 20"  Force: 29 lbs.  Stroke: 8"

Stock# 7110041
BRI-MAR Steel Trailer Tongue Toolbox/Pump Box is designed to mount to the front of A-frame style BRI-MAR trailer. This toolbox/ pump box has pre-welded mounting brackets inside for a battery and holes in the box for wiring or hydraulic hoses. Measures 36.5" Wide x 19" Deep x 12.5" High

Stock# 7110042
BRI-MAR Locking Pump Box Paddle Latch includes two keys. Direct replacement for existing Bri-Mar pump box latches. Mounting hardware is not included.
