Paraiso Electric Brakes

Paraiso Electric Brakes

Electric brake systems consist of components mounted both on the tow vehicle and the trailer. For these systems to operate properly, the trailer wiring end plug on the trailer must match the wiring pattern of the mating plug on the tow vehicle. The most common plug types for electric brake trailers are the 6-pole round pin and 7-pole RV flat blade connectors. An ELECTRONIC BRAKE CONTROLLER must be properly mounted at the dash area of the tow vehicle. The brake controller allows for adjustment of braking strength and also offers a manual brake control for emergency braking. Some controllers are available with a pre-wired quick connect plug for easy installation on select late model vehicles that have a factory tow prep package. Be certain to follow the installation instructions and to use the proper gauge wire and circuit breaker size when installing a brake controller on your tow vehicle.

The trailer side of an electric brake system consists of left & right ELECTRIC BRAKE ASSEMBLIES, drum & hub assemblies, EMERGENCY BREAKAWAY KIT-(battery w/box, breakaway switch, trickle charger) and end plug connector.

-39%

PARAISO 10" x 2-1/4" Electric Brake Assy. - Left Hand / 3.5k #AB1

Stock# 7160001
PARAISO 10" x 2-1/4" Left Hand complete electric brake assembly.
This brake is rated to a maximum capacity of 3,500 lbs. per pair.
Learn More

Special Price $23.50 was $38.50
-39%

PARAISO 10" x 2-1/4" Electric Brake Assy. - Right Hand / 3.5k #AB2

Stock# 7160002
PARAISO 10" x 2-1/4" Right Hand complete electric brake assembly.
This brake is rated to a maximum capacity of 3,500 lbs. per pair.
Learn More

Special Price $23.50 was $38.50
-34%

PARAISO 10" x 2-1/4" Dacromet Electric Brake Assy. - Left Hand / 3.5k #AB3

Stock# 7160003
PARAISO 10" x 2-1/4" Left Hand complete electric brake assembly. Dacromet Coating offers great protection in salty environments. This brake is rated to a maximum capacity of 3,500 lbs. per pair.
Learn More

Special Price $29.50 was $44.50
-34%

PARAISO 10" x 2-1/4" Dacromet Electric Brake Assy. - Right Hand / 3.5k #AB4

Stock# 7160004
PARAISO 10" x 2-1/4" Right Hand complete electric brake assembly. Dacromet Coating offers great protection in salty environments. This brake is rated to a maximum capacity of 3,500 lbs. per pair.
Learn More

Special Price $29.50 was $44.50
PARAISO 10" x 2-1/4" Self-Adjust Electric Brake Assy - L.H. / 3.5k #AB5

Stock# 7160005
PARAISO 10" x 2-1/4" Forward Self-Adjusting Left Hand complete electric brake assembly. This brake is rated to a maximum capacity of 3,500 lbs. per pair. Self-Adjusting brakes automatically adjust to proper clearances during travel allowing you to stop with confidence.
Learn More

$39.50
PARAISO 10" x 2-1/4" Self-Adjust Electric Brake Assy - R.H. / 3.5k #AB6

Stock# 7160006
PARAISO 10" x 2-1/4" Forward Self-Adjusting Right Hand complete electric brake assembly. This brake is rated to a maximum capacity of 3,500 lbs. per pair. Self-Adjusting brakes automatically adjust to proper clearances during travel allowing you to stop with confidence.
Learn More

$39.50
PARAISO 12" x 2" Electric Brake Assembly - Left Hand / 6-7K #AB15

Stock# 7160009
PARAISO 12" x 2" Left Hand complete electric brake assembly. Mounts to 5-hole axle brake flange. This brake is rated to a maximum capacity of 7,000 lbs. per pair. (Black Wire Magnet)
Learn More

$46.50
PARAISO 12" x 2" Electric Brake Assembly - Right Hand / 6-7K #AB16

Stock# 7160010
PARAISO 12" x 2" Right Hand complete electric brake assembly. Mounts to 5-hole axle brake flange. This brake is rated to a maximum capacity of 7,000 lbs. per pair. (Black Wire Magnet)
Learn More

$46.50
-28%

PARAISO 12" x 2" Dacromet Electric Brake Assy. - Left Hand / 6-7K #AB17

Stock# 7160017
PARAISO 12" x 2" Left Hand complete electric brake assembly. Dacromet Coating offers great protection in salty environments. This brake is rated to a maximum capacity of 7,000 lbs. per pair.
Learn More

Special Price $39.50 was $54.50
-28%

PARAISO 12" x 2" Dacromet Electric Brake Assy. - Right Hand / 6-7K #AB18

Stock# 7160018
PARAISO 12" x 2" Right Hand complete electric brake assembly. Dacromet Coating offers great protection in salty environments. This brake is rated to a maximum capacity of 7,000 lbs. per pair.
Learn More

Special Price $39.50 was $54.50
PARAISO 12-1/4" x 3-3/8" Electric Brake Assy - Left Hand / 8k #AB35

Stock# 7160013
PARAISO 12-1/4" x 3-3/8" FSA Left Hand complete electric brake assembly. This brake is rated to a maximum capacity of 8,000 lbs. per pair.
Learn More

$94.50
PARAISO 12-1/4" x 3-3/8" Electric Brake Assy - Right Hand / 8k #AB36

Stock# 7160014
PARAISO 12-1/4" x 3-3/8" FSA Right Hand complete electric brake assembly. This brake is rated to a maximum capacity of 8,000 lbs. per pair.
Learn More

$94.50
PARAISO 12-1/4" x 3-3/8" Electric Brake Assy - Left Hand / 10K #AB37

Stock# 7160019
PARAISO 12-1/4" x 3-3/8" FSA Left Hand complete electric brake assembly. This brake is rated to a maximum capacity of 10,000 lbs. per pair.
Learn More

$96.50
PARAISO 12-1/4" x 3-3/8" Electric Brake Assy - Right Hand / 10K #AB38

Stock# 7160020
PARAISO 12-1/4" x 3-3/8" FSA Right Hand complete electric brake assembly. This brake is rated to a maximum capacity of 10,000 lbs. per pair.
Learn More

$96.50
-34%

PARAISO 12-1/4" x 5" Electric Brake Assy - Left Hand / 12k #AB51

Stock# 7160044
PARAISO 12-1/4" x 5" HD FSA Left Hand complete electric brake assembly. Forward Self Adjusting / Heavy Duty application.
Learn More

Special Price $69.50 was $105.00
-34%

PARAISO 12-1/4" x 5" Electric Brake Assy - Right Hand / 12k #AB52

Stock# 7160045
PARAISO 12-1/4" x 5" HD FSA Right Hand complete electric brake assembly. Forward Self Adjusting / Heavy Duty application.
Learn More

Special Price $69.50 was $105.00
PARAISO 12" x 2" Brake Drum, 6 on 5.5" #DK2

Stock# 7160025
PARAISO 6-Studs on 5-1/2" Bolt Circle Trailer Brake Drum designed for 5.2 - 6K axles. Includes wheel bearings 1-1/4" (15123) x 1-3/4" (25580), grease seal (I.D. = 2.25"), lug nuts, cotter pin, grease cap, and cap plug.
Learn More

$99.75
PARAISO 12" x 2" Brake Drum, 8 on 6.5" #DK3

Stock# 7160026
PARAISO 8-Studs on 6-1/2" Bolt Circle Trailer Brake Drum designed for 7K axles. Includes wheel bearings 1-1/4" (14125A) x 1-3/4" (25580), grease seal (I.D. = 2.25"), 9/16"-18 lug nuts, cotter pin, grease cap, and cap plug.
Learn More

$109.00
-25%

PARAISO 12-1/4" x 3-3/8" Drum 8K, 5/8"-18 Studs #DK4

Stock# 7160039
PARAISO Brake Drum, 8 stud on 6.5" bolt circle, 5/8"-18 studded, 4.75" pilot dia. Includes 1-1/4" (02475) x 1-3/4" (25580) bearings, Grease seal, Threaded Grease Cap w/Rubber plug, "O" Ring, 90° cone nuts.
Learn More

Special Price $139.00 was $185.00
-36%

PARAISO 12-1/4" x 3-3/8" Drum 9K & 10K, 5/8"-18 Studs #DK5

Stock# 7160040
PARAISO Brake Drum, 8 stud on 6.5" bolt circle, 5/8"-18 studded, 4.75" pilot dia. Includes 2-1/4"(387A) x 1-3/4"(25580) bearings, Oil seal, Oil cap w/Rubber plug, "O" Ring, 90° cone nuts & Clamp Ring.
Learn More

Special Price $159.00 was $249.00
-39%

PARAISO 12-1/4" x 5" Drum 12K, 5/8"-18 Studs #DK6

Stock# 7160041
PARAISO Brake Drum, 8 stud on 6.5" bolt circle, 5/8"-18 studded, 4.75" pilot dia. Includes 2-1/4"(28682) x 2-5/8"(3984) bearings, Oil seal, Oil cap w/Rubber plug, "O" Ring, 90° cone nuts & Clamp Ring.
Learn More

Special Price $199.00 was $325.00
-50%

TPS Brake Mounting Nut, 7/16"-20

Stock# 7155039
TPS brake mounting nut is used to attach brake backing plates to axle brake flanges.
Learn More

Special Price $0.50 was $1.00
-53%

TPS Brake Mounting Lock Washer (7/16") #TPSLW2

Stock# 7155040
TPS brake mounting lock washer is used to attach brake backing plates to axle brake flanges.
Learn More

Special Price $0.35 was $0.75
TPS Brake Mounting Nut, 3/8"-24

Stock# 7155037
TPS brake mounting nut is used to attach brake backing plates to axle brake flanges.
Learn More

$1.00
TPS Brake Mounting Lock Washer (3/8") #TPSLW1

Stock# 7155038
TPS brake mounting lock washer is used to attach brake backing plates to axle brake flanges.
Learn More

$0.75
