VELVAC Universal Dash Air Valve #032253

VELVAC Universal Dash Air valve is primarily used on vehicles to apply and release service in air systems.

Specifications:

• Two-position three-way air valves
• Include DOT compliant FMVSS 106) push-to-connect fittings for 1/4 inch tubing
• Built-in standard four pin electrical connector for backlit function
• Additional rear port used to easily jumper air lines between valves
• Fit standard 22mm x 44mm openings, easily replacing valves found on many current model trucks
• Operating Temperature : -10° to +160°F
• Rated Pressure : 150 psi maximum
• Rated Current Load : 1 amp at 14 VDC (max)
• Electric Connector : Valve connector mates with metric-Pack 150 series connector Part No. 12045813 with female terminals (for reference only-not available from Velvac and not included)
